Uninet iColor 560 WTP/DTF

Uninet iColor 560 WTP/DTF

$3,995.00
$4,295.00 $3,995.00
Sale Sold out
Bundles

IColor™ 560

The UNINET® IColor™ 560 is the ultimate white toner transfer printer combined with exclusive white overprint® and underprint® capabilities in a single pass for transfer production of apparel, textile, hard surfaces, and more.

The Best-in-Class Total Cost of Ownership, Plain and Simple.

With its higher yield white toner cartridge capacity of 7,000 pages + full-color capabilities, the IColor™ 560 combines absolute versatility with a superstar performance for on-demand printing of short to mid-run transfer production of garments, hard surfaces, product customization, merchandising materials, and more.

Buy One. Get Six!

The IColor™ 560 does it all.

  1. White overprint® for textile and apparel applications
  2. White underprint® for non-transfer applications
  3. Dye Sublimation applications
  4. Fluorescent colors and Clear
  5. Regular CMYK printing
  6. Gold and Silver color printing capabilities



What Sets the IColor™ 560 Apart?

  • New for 2023 (120v models) - Now includes the exclusive White Toner Master Class.
  • Exclusive white overprint® and underprint® capabilities in a single pass.
  • Gold and Silver optional toner upgrade kits available.
  • IColor™ White Toner Higher Yield cartridge capacity of 7,000 pages extending print cycles and considerably reducing printing costs.
  • WiFi as well as WiFi direct, and NFC capable (in CYMK mode).
  • Cutting-edge technology to produce digital transfers in a fast, and efficient fashion to be pressed onto virtually any type of dark or light-colored textile and hard surface materials such as ceramic, glass, wood, acrylics, metal, magnetic sheeting, leather, and more.
  • Incorporated IColor™ ProRIP Essentials software for automated production-level printing with advanced color management and customized print modes; as well as color changes, image manipulation, and rasterization on the fly.
  • Exclusive IColor™ SmartCUT Enhanced RIP Software software included for oversized images like tabloid and greater.
  • A toner-based system that does not require the maintenance associated with ink-based printers.
  • Exceptional 2400 dpi resolution vs. the competition.
  • Includes All-in-one five toner cartridges & drum printing system W/C/M/Y + BK for full color and white printing (CMYW plus True Black).
  • Easily swap back and forth between regular and specialty cartridge kits, eliminating the need to purchase separate machines to accomplish each function.
  • A complete seamless transfer printing solution comprised of hardware, software, and transfer papers.
  • The definition of “workhorse” for any startup!

Enter the World of the IColor™ 560

The most complete seamless digital transfer printing solution comprised of hardware, software, and transfer papers in the industry.

The IColor™ 560 provides cost-effective fabric transfer production without the constant maintenance associated with direct-to-garment or silk-screening systems.

Get exceptional 2400 dpi resolution image quality results versus the competition combined with the IColor™ Transfer Papers available in a variety of sizes and textures featuring a weed-free system allowing you to affordably express your creativity.

System Specifications

Print Speed

Up to 8 ppm on transfer paper; up to 26 ppm on standard copy paper

Processor

350 MHz

Duty Cycle

Up to 65,000 pg/mo.

Duplex

Standard

Memory

256 MB

Resolution

2400 x 600 dpi

Emulation

PostScript® 3™

Operating System

Standalone and network - Microsoft Windows® 8 / 10 / 11 (x32 & x64)

Interfaces

10/100-TX Ethernet, Wireless LAN, High-Speed USB v2.0

Paper Capacity

Standard 251 sheets; handles transfer media, card and mailing label stock

Paper Cassette

251 sheets Legal/Letter/Universal

Paper Sizes (Min./Max.)

Tray 1: A4, A5, A6, B4, B5, Legal, Letter, HLT;
Bypass tray: A4, A5, A6, B5, B6, Legal, Letter, HLT

Paper Weight

Bypass Tray 16 lb. bond to 43 lb. index (60 to 163 gsm); Paper Cassette 16 lb. bond to 43 lb. index (60 to 163 gsm)

Toner Cartridge Yield
All rated at 5% toner coverage

Extended CMYK: 7,000 pages
Extended White: 7,000 pages
Starter CMYK: 1,000 pages
Starter White: N/A

Size

(WxDxH): 15.7" x 17.7" x 13.1" (400 x 450 x 334 mm)

Weight

55 lb. (25 kg)

Power

120v and 230v

Power Consumption (maximum)

11 amps (120v models) or 6 amps (230v models)


Warranty

1 year (parts and labor)

System Includes

  • The IColor 560 comes standard with five toner cartridges for full color and white printing (CMYW plus True Black).
  • IColor ProRIP Essentials Transfer software for white overprint® and underprint® functionality, as well as color changes, image manipulation, and rasterization on the fly!
  • Exclusive IColor SmartCUT Enhanced RIP Software included allowing the user to print oversized images like tabloid and greater, plus Selective Masking and Real Preview Tools.
  • White Toner Beginners Notebook.
  • White Toner Master Class Video Series and Quick Start Video



How We Compare to Our Competitors

Notable Distinctions
  • White Underprinting® Technology allows printing on clear or dark surfaces without heat pressing.
  • Duplex printing option for double-sided output on regular paper.
  • Includes a free graphics package for your creative projects.
  • Comes with the White Toner Notebook for essential training and project inspiration.
  • Supports specialty toner kits: sublimation, fluorescent, gold/silver, clear, and security toners (optional).
Some Differences
  • We offer free replacement parts under warranty—our competitors only offer onsite service.
  • Supports banner printing up to 11.8" x 52", unlike our competitors.
  • Includes the White Toner Master Class Video Series and printed guide for professional training.
  • Comes with the full IColor™ ProRIP™ Software—our competitors ship with a basic version.
  • Includes SmartCUT™ for oversized graphics—competitors don’t support it.
  • Ships with double the toner capacity: 10,000-page white toner cartridge.
  • Fluorescent white toner provides higher brightness and density.
  • Print resolution: 1200 x 1200 dpi (vs. 600 dpi on competitors).
  • Faster output: 6.5 seconds to first page (vs. 9.5 seconds).
  • Memory: 1GB (vs. 256MB from competitors).
  • Features a modern touchscreen display (vs. physical buttons).
  • Wi-Fi connectivity included—competitors require hardwire only.
Same Benefits
  • Prints white on top of color in one pass for transfers.
  • Presses on the same range of materials.
  • Low-maintenance compared to ink-based systems.
  • Similar footprint and weight.
  • Includes RIP software for controlling white overprint.
  • Ships with 2,500 starter color cartridges (CMY).
  • Two-cartridge system (toner + drum).
  • Swap between black and white cartridges as needed.
  • 2-year warranty included.
